Kontron KT690/mITX - Advanced Settings - IDE Configuration

KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 67 of 91
8.3.2 Advanced settings – IDE Configuration
BIOS SETUP UTILITY
Advanced
IDE Configuration
OnBoard PCI IDE Controller [Primary]
OnChip SATA Type [Enabled]
OnChip SATA Channel [Native IDE]
Primary IDE Master : [Hard Disk]
Secondary IDE Master : [Not Detected]
Third IDE Master : [Not Detected]
Third IDE Slave : [Not Detected]
Fourth IDE Master : [Not Detected]
Fourth IDE Slave : [Not Detected]
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
ATA(PI) 80Pin Cable Detection [Host & Device]
Options
Controls the 40Pin
PATA connector and
CF interface.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
OnBoard PCI IDE Controller Disable
Primary
Controls the 40Pin PATA connector and CF
interface.
Feature Options Description
OnChip SATA Channel
Enabled
Disabled
Enabled/Disabled the SATA circuit
OnChip SATA Channel
Native IDE
RAID
AHCI
Legacy IDE
Native IDE
RAID (Press <Ctrl><F> to enter RAID BIOS menu)
AHCI
Legacy IDE
Feature Options Description
Hard Disk Write Protect
Disabled
Enabled
Disabled
Enhanced
IDE Detect Time Out (Sec) 0
5
10
15
20
25
30
35
Select the time out value for detecting ATA/ATAPI
device(s)
ATA(PI) 80Pin Cable
Detection
Host & Device
Host
Device
Select the mechanism for detecting 80Pin ATA(PI)
Cable
