Kontron KT690/mITX - 8.3 Advanced Menu

KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 66 of 91
8.3 Advanced Menu
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
Advanced Settings
>
>
>
>
>
>
>
>
>
>
>
>
Warning: Setting wrong values in below sections
may cause system to malfunction.
CPU Configuration
IDE Configuration
LAN Configuration
Floppy Configuration
SuperIO Configuration
Hardware Health Configuration
Voltage Monitor
ACPI Configuration
Remote Access Configuration
Trusted Computing
USB Configuration
Clock Generator Settings
Configure CPU.
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
8.3.1 Advanced settings – CPU Configuration
BIOS SETUP UTILITY
Advanced
CPU Configure
Module Version –13.14
AGESA Version: 02.08.13
Physical Count: 1
Logical Count : 2
AMD Turion(tm) 64 X2 Mobile Technology TL-52
Revision: F2
Cache L1 : 256 KB
Cache L2 : 1024 KB
Speed : 1600MHz
Current FSB Multiplier: 8x
uCode Patch Level : 0x62
Able to Change Freq. : Yes
Maximum FSB Multiplier: 8x
Secure Virtual Machine Mode [Enabled]
Runtime Legacy PSB [Disabled]
C1E Support [Disabled]
Enable/Disable
Secure Virtual
Mode (SVM)
<- Select Screen
|| Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Secure Virtual Machine Mode
Enabled
Disabled
Enable/Disable Secure Virtual Mode (SVM)
Runtime Legacy PSB Enabled
Disabled
Enable/disable the generation of Power State block
for use of PowerNow™ driver in single core system
C1E Support Enabled
Disabled
Enable/disable C1E support.
