Kontron KT690/mITX - 4.4 Display Connectors

KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 30 of 91
4.4 Display Connectors
The KT690 board provides:
1. Analog CRT interface (Front panel)
2. Digital DVI (DVI-D) (Front panel)
3. LVDS connector (internal connector)
4. TV-Out (KT690/mITX Front, KT690-FW/mITX Internal pin header)
The KT690 board does not support ADD2 / SDVO cards on the PCI Express x16 connector.
The KT690 integrates the ATI Radeon™ X1250 Graphics Core with support for Dual Clone display and Dual
independent display.
The supported combinations are listed in the below matrix:
Primary Display
CRT DVI-D LVDS TV-Out
CRT
Clone / Dual Clone / Dual Not supported
DVI-D
Clone / Dual
Clone / Dual Clone / Dual
LVDS
Clone / Dual Clone / Dual
Clone / Dual
Secondary
Display
TV-Out
Not supported Clone / Dual Clone / Dual
