4.6.2 CF Connector (CF)
This connector is mounted on the topside of the KT690/mITX (CF is not available on KT690-FW/mITX).
The CF socket support DMA/UDMA modules up to UDMA2.
NOTE: If the CF connector is used then only one PATA device is supported and only by use of 40-wire cable
(not 80-wire cable). Optionally use SATA device(s). Normally CF is Master and then possible PATA device
must be Slave.
Note
Pull
U/D Ioh/Iol Type Signal
PIN
Signal Type Ioh/Iol
Pull
U/D Note
2 - - - NC 26 1 GND PWR - - 1
- TBD IO DA11 27 2 DB3 IO TBD -
- TBD IO DA12 28 3 DB4 IO TBD -
- TBD IO DA13 29 4 DB5 IO TBD -
- TBD IO DA14 30 5 DB6 IO TBD -
- TBD IO DA15 31 6 DB7 IO TBD -
- TBD O HDCSA1# 32 7 HDCSA0# O TBD -
- - - NC 33 8 GND PWR - -
- TBD O IORA# 34 9 GND PWR - -
- TBD O IOWA# 35 10 GND PWR - -
- - PWR 5V 36 11 GND PWR - -
8K2 - I HDIRQA 37 12 GND PWR - -
- - PWR 5V 38 13 5V PWR - -
- - PWR GND 39 14 GND PWR - -
- - - NC 40 15 GND PWR - -
- TBD O RESET_C# 41 16 GND PWR - -
4K7 - I IORDYA 42 17 GND PWR - -
- - I DDRQA 43 18 DAA2 O - -
- - O DDACKA# 44 19 DAA1 O - -
- - I HDACTA# 45 20 DAA0 O - -
- - I CBLIDA# 46 21 DB0 IO TBD -
- TBD IO DB8 47 22 DB1 IO TBD -
- TBD IO DB9 48 23 DB2 IO TBD -
- TBD IO DB10 49 24 NC
1 - - PWR GND 50 25 NC - - - 2
Note 1: Pin is longer than average length of the other pins.
Note 2: Pin is shorter than average length of the other pins.
