3. System specification
3.1 Component main data
The table below summarises the features of the KT690 and KT690-FW embedded motherboards.
Form factor
KT690/mITX and KT690-FW/mITX: mini ITX (170.18millimeters by 170.18millimeters)
Processor
• Support for Mobile AMD Sempron™, AMD Turion™ 64 and AMD Turion™ 64 X2
Mobile Processors for S1 socket
• 35W maximum TDP
• 1.6GT/s HyperTransport™ link, 800 MHz, 16bit/16bit
• Hypertransport™ 1.0 Tunnel (I/O Bus) speed of 800MHz
• Internal L1 cache of 128KB (Single core CPUs) / 128KB x2 (Dual core CPUs)
• Internal L2 cache of 128/256/512KB (Single core CPUs) / 512KB x2 (Dual core CPUs)
• Processor technology of 65nm / 90nm
• DDR2 memory controller and bus interface
Memory
• Dual Channel DDR2 memory architecture
• 2 pcs DDR2 SODIMM 200pin DRAM sockets onboard.
• Support for DDR 400/533/667MHz unbuffered memory (PC2-3200/PC2-4200/PC2-
5300)
• Support system memory from 256MB and up to 4GB
• ECC not supported
Chipset
AMD Chipset consisting of:
• AMD M690T northbridge ( graphics tunnel)
• ATI SB600 southbridge (I/O hub)
Video
• Integrated ATI Radeon™ X1200 graphics core
o CRT Out connector
o DVI-D connector (Digital only)
o Onboard LVDS connector
o TV-Out connector**
• Dual independent pipe support: Mirror and Dual Independent displays supported.
• Full DirectX® 9.0 support
• Maximum resolution of 2048x1536 @ 32bpp for a maximum pixel clock speed of
400MHz.
• LVDS interface supports dual channel, 24bit OpenLDI/ SPWG panels.
• HyperMemory
TM
allowing up to 256MB dynamically allocated Video Memory (System
memory is allocated when it is needed).
Audio
Audio, 7.1 and 7.2 Channel High Definition Audio Codec using the Realtek ALC888 codec
• Line-out
• Line-in
• Surround output: SIDE, LFE, CEN, BACK and FRONT
• Microphone: MIC1, MIC2
• CDROM in
• SPDIF Interface
Onboard speaker
(continues)
