6.2 PCI devices
Bus
#
Device
#
Function
#
Vendor
ID
Device
ID
IDSEL Chip Device Function
0 0 0 1002h 7910h SB600 Host brigde
0 1 0 1002h 7912h SB600 Pci to Pci Brigde
0 6 0 1002h 7916h SB600 Pci to Pci Brigde
0 7 0 1002h 7917h SB600 Pci to Pci Brigde
0 18 0 1002h 4380h SB600 IDE Controller
0 19 0 1002h 4387h SB600 USB
0 19 1 1002h 4388h SB600 USB
0 19 2 1002h 4389h SB600 USB
0 19 3 1002h 438Ah SB600 USB
0 19 4 1002h 438Bh SB600 USB
0 19 5 1002h 4386h SB600 USB
0 20 0 1002h 4385h SB600 SMBus
0 20 1 1002h 438Ch SB600 IDE Controller
0 20 2 1002h 4383h SB600 HD Audio
0 20 3 1002h 438Dh SB600 ISA Brigde
0 20 4 1002h 4384h SB600 Pci to Pci Brigde
0 24 0 1002h 1100h SB600 Host brigde
0 24 1 1022h 1101h SB600 Host brigde
0 24 2 1022h 1102h SB600 Host brigde
0 24 3 1022h 1103h SB600 Host brigde
1 5 0 1022h 791Fh RS690 VGA Controller
2 0 0 10ECh 8168h RTL8111 Ethernet
3 0 0 10ECh 8168h RTL8111 Ethernet
4 0 0 - - - PCI Slot
* - - - - - PCI-E Slot
When a PCI-E card is used it could change the BUS number on other PCI-E and PCI devices like
RTL8111b.
Note: PCI slot supports PCI BUS Mastering.
