Kontron KT690/mITX - Advanced Settings - USB Mass Storage Device Configuration; Advanced Settings - Clock Generator Settings

KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 76 of 91
8.3.12 Advanced settings – USB Mass Storage Device Configuration
BIOS SETUP UTILITY
Advanced
USB Mass Storage Device Configuration
USB Mass Storage Reset Delay [20 Sec]
Device #1 JetFlash TS256MJF2L
Emulation Type [Auto]
Number of seconds POST
waits for the USB mass
storage device after
start unit command.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
8.3.13 Advanced settings – Clock Generator Settings
BIOS SETUP UTILITY
Advanced
Clock Generator Settings
Spread Spectrum [Disabled]
[Disabled]
[0.5%]
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
USB Mass Storage Reset
Delay
10 Sec
20 Sec
30 Sec
40 Sec
Number of seconds POST waits for the USB mass
storage device after start unit command.
Emulation Type
Auto
Floppy
Forced FDD
Hard Disk
CDROM
If Auto, USB devices less than 530MB will be
emulated as Floppy and remaining as hard drive.
Forced FDD option can be used to force a HDD
formatted drive to boot as FDD (Ex. ZIP drive).
Feature Options Description
Spread Spectrum
Disabled
0.5%
Controls the clock generator clock output to enable
(0.5%) or disable Spread spectrum
