KORG D12 Guided Tour
33
8. Press [UNDO] (lit), and note the two “Levels” of “FadeTrack” indicated in the display, as well as the “CopyTrack” procedure
you performed in a previous section. The most current level of editing is indicated as “Level01”.
9. Rotate the [DIAL] to highlight “Level02” (“FadeTrack”), then u to the “Undo” button, and press ENTER.
10. Press [IN/LOC1], then press [PLAY] to playback the audio before the first fade-out that you performed (Level02), then press
[STOP].
11. Rotate the [DIAL] to select “Level01”, then u to ”Redo” and press ENTER.
12. Press [IN/LOC1], then press [PLAY] to playback the last fade-out you performed (Level01).
13. Press [STOP], then u to ”OK” and press ENTER to exit Undo mode.
Note: The Undo/Redo function can be used for recording, track editing, and WAV file import operations. The “Current”
level of Undo is indicated in the upper left of the UNDO display.
Also Note: The levels (99, 8 or 1) of undo can be set by selecting the “Level” button in the UNDO page, and then selecting the
desired level. For more information on the UNDO function, see the D12 Owner’s Manual, page 99.
Guitar and Insert effect / Rhythm Pattern demo
Recording source for this section: The following section suggests a guitar as the input source. If you would like to use another
instrument such as keyboards, connect the source stereo outputs to front panel adjacent inputs 3 and 4, and in INPUT mode, assign
the signal from these inputs to one of the stereo paired channels (7/8, 9/10, 11/12). Alternatively, you can continue to use the internal
microphone, as you did in previous exercises.
Create a new song and connect a guitar:
1. Press [SONG/CD] until you select the “SelSong” tab.
2. u to the “New” button and press ENTER, then u to the “OK” button in the display and press ENTER to select a new empty
song location.
3. Lower the PHONE or MONITOR levels to “0”, and the MASTER / Channel faders to “oo”.
4. Connect a guitar to the front panel GUITAR IN jack.
5. Press the Channel 1 [TRACK STATUS] key until it lights orange (Input status, not Record status).
6. Rotate the INPUT 1 TRIM knob as high as possible without allowing the LED to light red (input clipping) as you play, and then
raise the Track 1 Channel fader to the “0” position. Note: View the Pre Fader level in the METER/TRACK VIEW display.
7. Play the guitar, and set the MASTER Fader and PHONE or MONITOR Levels to comfortable listening positions.
8. Press [INPUT/TUNER] until you select the “Tuner” tab, and make sure that the “Input 1” radio button is selected, then tune
your guitar as you watch the Tuner meter in the upper left of the display.
