microSAMPLER
68
* Specifications and appearance are subject to change without notice for improve-
ment.
Specifications
Keyboard
37-note (natural-touch mini-keyboard, velocity sensi-
tive)
Banks 8 user banks (A–H), 1 ROM bank
Sampler
Sampling types LOOP / ONE SHOT / GATE / AUTO NEXT / KEY GATE
Sampling sources Audio input ( MIC/LINE)
Resampling
Sampling rates 48 kHz / 24 kHz / 12 kHz / 6 kHz
Sampling time Approximately 160 seconds per bank (159.7 seconds for
mono, sampling rate 48 kHz)
Sample playback
Polyphony Maximum 14 notes (7 notes if using time stretch play-
back)
Playback sampling rate 48 kHz
Pattern sequencer
Number of patterns 16 patterns per bank
Maximum number of
notes
Maximum of approximately 64,000 notes per bank
(maximum of approximately 16,000 notes per pattern)
Resolution 96 ticks per quarter note
Number of measures in
a pattern
1–99
Recording method Realtime recording
Effects
Structure One master effect
During sampling, choose either one master effect or
audio-in insert effect
Effect types Choose one of 21 types
Inputs
AUDIO IN [L/MONO], [R]
jacks - rear panel
Connector: 1/4" phone jack (unbalanced)
Maximum input level: -17 dBu @ GAIN: max
Input impedance: 7 kΩ
AUDIO IN [ MIC] jack
- front panel
Connector: XLR jack
Maximum input level: -40 dBu @ GAIN: max
Input source impedance: 14 kΩ
Output
OUTPUT [L/MONO],
[R] jacks
Connector: 1/4" phone jack (unbalanced)
Maximum output level: +4 dBu @ 10 kΩ load
Output impedance: 1 kΩ
Headphone jack Connector: 1/4" stereo phone jack
Maximum output level: 10 mW + 10 mW @ 32Ω load
Output impedance: 10Ω
MIDI connectors IN, OUT
USB connector B-type connector
Display Custom LCD
Power supply
DC9V
When using batteries: six AA alkaline batteries
Battery life: approximately 3 hours
Dimension (W x D x H) 516 x 238 x 65 mm / 20.31 x 9.37 x 2.56 inches
Weight 1.9 kg / 4.19 lbs
Included items
AC adapter
Mic
Owner’s manual
