EG:EnvelopeGenerator
Youcanmaketime-basedchangesto
theVCA,pitchorcutobyusingthe
EG.
TYPE switch [ , , ]
TheseingsmadeherewillchangetheVCAandTARGETparametersover
time,asshownbelow.
WhenusingGATE,time-basedchangescannotbemadetotheVCA.
ATTACK knob [0...1023]
TheATTACKspeciesthetimerequiredfortheEGtoreachitsmaximumlevel
onceanewnoteisplayed.
DECAY knob [0...1023]
WhentheTYPEswitchissetto“A/D”or“GATE”,thissetstheamountoftime
untilthelevelbecomes0aerthemaximumlevelisreached.
WhentheTYPEswitchissetto“A/G/D”,thissetsthetimefromnote-o(when
thekeyisreleased)untilthelevelreaches0.
(Amp EG)
Attack Decay
0
Attack Decay
0
0
Int
Attack Decay
0
Int
Attack Decay
0
Int
0
PITCH,PITCH2(PitchEG),
CUTOFF (Filter EG)
(GATE)
(A/D: Attack/Decay)
(A/G/D: Attack/Gate/Decay)
