21
RATE knob
[0...1023 / 1/8, 1/16, 1/32...1/1024, 1/2048 / 4, 2, 1, 0, 3/4...1/64]
TherateknobadjuststhespeedoftheLFO.
TurningtheknobtotherightwillincreasetheLFOspeed.
ThevaluesindicatedheredependontheLFOBPMSync(p.33)seingsinthe
PROGRAMEDITmode,andtheMODEswitch,asshownbelow.
LFO BPM Sync MODE switch
O 0–1023
On FAST 1/8,1/16,1/32...1/1024,1/2048
On SLOW,1-SHOT 4–1/64
TIP
WhentheParameterDispofGLOBALEDITmodeissettoAll,you
canseethevalue(“ParameterDisp”,p.44).
INT knob [0...1023]
TheINTknobadjuststheintensityoftheLFO.
TurningtheknobtotherightwillincreasetheLFOintensity.
TIP
WhenturningtheINTknobwhileholdingdowntheSHIFTbuon,
theeectwillmoveinanegativedirection.
TARGET switch [PITCH, SHAPE, CUTOFF]
SelectstheparameterwheretheLFOmodulationwillbeapplied.
PITCH:ModulationisappliedtotheVCO1,2PITCH.
SHAPE:ModulationisappliedtotheVCO1,2SHAPE.
CUTOFF:ModulationisappliedtotheFILTERCUTOFF.
