5-8
The fuel gauge resistance and insufficient fuel warning setting
Now the resistance setting value is flashing!
The fuel gauge resistance setting range
: 100 Ù, 510 Ù, fuel switch.
The switch setting is for the fuel switch
only, can't be used for the fuel level
sensor.
If you don't install the fuel wiring, the
fuel gauge will not display.
In a 8 screen, press the Select button to enter
the fuel gauge resistance and insufficient fuel
warning setting screen.
EX. Now the fuel gauge resistance setting is
100 Ù and the insufficient fuel warning setting
is 30 %.
EX.
0
You want to change the fuel resistance
setting to 51 .
Press the Adjust button to choose the setting
value.
Ù
P.S.P.S.
Usually the fuel gauge resistance is 100 on YAMAHA
system, and 510 on HONDA system.
The insufficient fuel warning setting: When the fuel is
less than your setting, the fuel level gauge will flash to
warn you.
Ù
Ù
Press the Select button to enter the insufficient
fuel warning setting screen.
EX. Now the fuel gauge setting is changed from
100 to 510 .ÙÙ
EX. You want to set the insufficient fuel
warning setting at 20 %.
Press the Adjust button to choose the setting
value.
Now the insufficient setting value is flashing!
The insufficient fuel warning setting
range: 10~50 %. Setting unit: 10 %.
Press the Select button to return to a 8 setting
screen.
EX. Now the setting is changed from 30 % to
20 %.
When you leave this screen, the setting
is finished.
Press the Adjust button to select the other
setting screens.
Next page
If you just want to make this function setting, you could
press down the Select button for 3 seconds to back to
the main screen.
CDI & FI CDI & FI
