Koso RX2N - 3-1 Auto-checking Screen; Understanding the Meters Startup Sequence; 3-2 Meter Size; Physical Dimensions and Mounting Specifications

3-1
Off
Check 1
Check 2
Check 3
On
100.7 mm
Auto-checking screen
It will enter the setting screen automatically when the first time you start it.
11 mm
52 mm
Check 4
Check 5
Check 6
Check 7
Check 8
3-2
26.5 mm 32.5 mm
38.42 mm
135.7 mm
26.5 mm23.2 mm
Meter size
CDI & FI CDI & FI
