Kramer VP-440X User Manual

Kramer Electronics Ltd.
VP-440X – Introduction
3
• HDMI Support – HDR10, CEC, x.v.Color™ (on input), 7.1 PCM, Dolby TrueHD/DTS-HD
(by-pass mode).
Advanced and User-friendly Operation
• A USB port for upgrading the firmware.
• Firmware Upgrade – Ethernet-based, via a user-friendly software upgrade tool.
• Built-in video Proc-Amp – color, hue, sharpness, contrast, and brightness are set
individually for each input.
• Bidirectional RS-232 Extension – Serial interface data flows in both directions, on each
extension line, enabling data transmission and control of devices.
• Diverse Control Options – Control the unit using an OSD (On-Screen Display) via front
panel buttons, embedded webpages via Ethernet and/or serial communication via
RS-232 transmitted by a PC, touch screen system or other serial controller. Additionally,
connect to the contact closure connector for remote switching of sources and for toggling
the display ON and OFF.
• An OSD (On-Screen Display) – for making adjustments – that can be located anywhere
on the screen.
• Efficient power-saving features.
• Advanced EDID management per input.
• Includes non-volatile memory that retains the last settings after switching the power off
and then on again.
Flexible Connectivity
• Flexible Digital and Analog Audio – Select a dedicated unbalanced analog audio input to
embed into each input. In addition, a microphone input is provided on the front panel for
mixing, switching or talk-over (ducking). Any of the signals can play audio through the
unbalanced audio output.
• 5 input buttons for switching a selected input to the outputs.
• Scaled video outputs – up to 4K60 4:4:4.
• Embedded audio and analog audio on the HDMI inputs, as well as an analog audio input
to accompany the VGA input.
• Unbalanced analog audio output.
Typical Applications
VP-440X is ideal for the following typical applications:
• Educational – classrooms, lecture theatres where 18G 4K support is required.
• Projection systems in conference rooms, boardrooms, hotels and churches requiring a
4K presentation switcher / scaler.
• Home theatre up-scaling.

Kramer VP-440X Specifications

General

Control type	Buttons
Product color	Black
EDID management	Yes
Housing material	Aluminum
Scaled resolutions	640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1280 x 768, 1280 x 800, 1360 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 3840 x 2160
HDMI in	4
RJ-45 ports quantity	2
Number of HDMI outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
HDCP version	1.4/2.2
Supported frame rate	24, 25, 30, 50, 60 fps
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Supported chroma subsampling	4:4:4
Power consumption (typical)	18 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	212 mm
Package width	351 mm
Package height	72 mm
Package weight	1600 g

Weight and Dimensions

Depth	163 mm
Width	214.6 mm
Height	43.6 mm
Weight	1100 g
