VS-211XS, VS-411XS – Using Embedded Web Pages
42
In this example, VS-411XS is connected to Kramer FC-28 control gateway (optional,
purchased separately). FC-28 includes various serial and non-serial ports and is set, for
example, to IP Address 192.168.1.40.
VS-411XS includes the following default ports:
Port Name
Type
Port Properties
Port Description
Comments
WOL-Echo
WOL
7
WOL-Discard
WOL
9
Internal
Internal
Enabling actions on the device
itself, such as switching an
input.
CEC-TV
CEC
0
Enabling actions such as display
on/off.
CEC-Broadcast
CEC
15
Non-Serial-on-GW
TCP
192.168.1.40,
5000
Gateway Non-
serial ports
For example, Relay, GPIO and
IR control on the FC-28
gateway.
You can add ports to Maestro (see www.kramerav.com/downloads/VS-211XS) for example, if
VS-411XS is connected to FC-28, you can add, for example, gateways for the two RS-232
serial ports on the FC-28.
Port Name
Type
Port Properties
Port Description
Comments
Display-Serial1-on-GW
TCP
192.168.1.40,
5001
FC-28 gateway;
RS-232 1 port
Serial 2-on-GW
TCP
192.168.1.40,
5002
FC-28 gateway:
RS-232 2 port
