Function
Description
Syntax
Parameters/Attributes
Example
CPEDID
Copy EDID data
from the output to
the input EEPROM.
Destination
bitmap size depends
on device properties
(for 64 inputs it is a
64-bit word).
Example: bitmap
0x0013 means
inputs 1,2 and 5 are
loaded with the new
EDID.
In certain products
Safe_mode is an
optional parameter.
See the HELP
command for its
availability.
COMMAND
#CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR>
or
#CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_mode<CR>
FEEDBACK
~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap<CR><LF>
~nn@CPEDIDedid_io,src_id,edid_io,dest_bitmap,safe_mode<C
R><LF>
edid_io – EDID source type (usually
output)
0 – Input
1 – Output
2 – Default EDID
3 – Custom EDID
src_id – Number of chosen source
stage
0 – Default EDID source
For inputs
0 – Input 1
1 – Input 2
2 – Input 3
3 – Input 4
For output - 1
For custom EDID -
edid_io – EDID destination type
(usually input)
0 – Input
dest_bitmap – Bitmap representing
destination IDs. Format: XXXX…X,
where X is hex digit. The binary form of
every hex digit represents corresponding
destinations.
0 – indicates that EDID data is not
copied to this destination.
1 – indicates that EDID data is copied
to this destination.
safe_mode – Safe mode
0 – device accepts the EDID as is
without trying to adjust
1 – device tries to adjust the EDID
(default value if no parameter is
sent)
Copy the EDID data
from the Output 1
(EDID source) to the
Input:
#CPEDID1,1,0,0x
1<CR>
Copy the EDID data
from the default EDID
source to the Input:
#CPEDID2,0,0,0x
1<CR>
DISPLAY?
Get output HPD
status.
COMMAND
#DISPLAY?out_index<CR>
FEEDBACK
~nn@DISPLAYout_index,status<CR><LF>
out_index – Number that indicates the
specific output:
1
status – HPD status according to signal
validation
0 – Signal or sink is not valid
1 – Signal or sink is valid
2 – Sink and EDID is valid
Get the output HPD
status of Output 1:
#DISPLAY?1<CR>
DPSW-STATUS?
Get the DIP-switch
state.
COMMAND
#DPSW-STATUS?dip_id<CR>
FEEDBACK
~nn@DPSW-STATUSdip_id,status<CR><LF>
dip_id – 1 to 4 (number of DIP
switches)
status – Up/down
0 – Up
1 – Down
Get the DIP-switch 2
status:
#DPSW-
STATUS?2<CR>
EDID-DC
Force removal of
deep color on EDID
or leaving it as in the
original EDID.
COMMAND
#EDID-DCin_index,deep_color_state<CR>
FEEDBACK
~nn@EDID-DCin_index,deep_color_state<CR><LF>
in_index – Number that indicates the
specific input:
1 – Input 1
2 – Input 2
3 – Input 3
4 – Input 4
deep_color_state –
0 – Don’t change
1 – Remove deep color
Remove deep color
on EDID for input 1.
#EDID-DC1,1<CR>
EDID-DC?
Get deep color
status on EDID.
COMMAND
#EDID-DC?in_index <CR>
FEEDBACK
~nn@EDID-DCin_index,deep_color_state<CR><LF>
in_index – Number that indicates the
specific input:
0 – Input 1
1 – Input 2
2 – Input 3
3 – Input 4
deep_color_state –
0 – Don’t change
1 – Remove deep color
Get deep color state
on EDID for input 2.
#EDID-DC?2<CR>
ETH-PORT
Set Ethernet port
protocol.
If the port number
you enter is already
in use, an error is
returned.
The port number
must be within the
following range: 0-
(2^16-1).
COMMAND
#ETH-PORTport_type,port_id<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
port_type – TCP/UDP
port_id – TCP/UDP port number
(0 – 65535)
Set the Ethernet port
protocol for TCP to
12457:
#ETH-PORTTCP,12
457<CR>
ETH-PORT?
Get Ethernet port
protocol.
If the port number
you enter is already
in use, an error is
returned.
The port number
must be within the
following range: 0-
(2^16-1).
COMMAND
#ETH-PORT?port_type<CR>
FEEDBACK
~nn@ETH-PORTport_type,port_id<CR><LF>
port_type – TCP/UDP
port_id – TCP/UDP port number
(0 – 65535)
Get the Ethernet port
protocol for UDP:
#ETH-PORT?UDP<C
R>
