VS-88H2A – Introduction
4
• Optional ARC from HDMI outputs and analog audio inputs to HDMI inputs.
• Supports Step-in function.
• Housed in a 19” 1U rack mountable enclosure, with rack ears included, and is fed from a
100-240 VAC universal switching power supply.
Typical Applications
The VS-88H2A is ideal for the following typical applications:
▪ Presentation and multimedia applications.
▪ Systems that require automatic HDMI routing.
Controlling your VS-88H2A
Control your VS-88H2A directly via the front panel push buttons (with on-screen menus), or:
• By RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller.
• Via the Ethernet using built-in user-friendly Web pages.

Kramer VS-88H2A Specifications

General

HDCP	Yes
Video bandwidth	60 Hz
Maximum resolution	- pixels
Number of displays supported	8
USB hub	No
Console ports	3.5mm headphone, HDMI, RJ–45, USB A
HDMI ports quantity	16
Power source	AC
Power plug type	Type F (CEE 7/4)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	330 mm
Package width	530 mm
Package height	107 mm
Package weight	3400 g
Cabling technology	-
Ethernet LAN (RJ-45) ports	1
Product color	Black

Weight and Dimensions

Depth	183 mm
Width	436.4 mm
Height	43.6 mm
Weight	2500 g
