3-4 Issue 05, 01/01 Krautkramer DM4E / DM4 / DM4 DL
Preparation for operation Connecting the probe
3.2 Connecting the probe
In order to prepare the DM4 for operation you must
connect the probe.
Select a probe which is suitable for your application.
Connect the probe cable to the socket on the top of
the instrument. Make certain that the “nose” of the
cable plug is completely seated into the round cavity
on the connection socket.
