7-2 Issue 05, 01/01 Krautkramer DM4E / DM4 / DM4 DL
7.1 Printing data
In connection with a printer having a serial interface
(e.g. Epson FX), the DM4 DL offers you the possibility
to print adjustment and measurement data as well as
statistical data.
In the DM4 DLs SPEC menu certain adjustments can
be carried out for printing the data:
BAUD Setting the data transfer rate
LANG Language selection
REP Selection of printer driver
HEAD Print “File header” with general data
STAT Print statistical data
For printing your measurement report you need:
• A printer with serial interface RS 232
• A data cable TGDL/PC with adapter GCH1 for
connecting the DM4 DL to the printer Epson FX (or
GCH3 for a printer Seiko DPU 414).
Documenting measurement values (DM4 DL only) Printing data
Preparing the printer
– Using the cable TGDL/PC, connect the printer to
the DM4 DL via the serial interface RS 232.
Data transfer for the DM4 DL is made in the following
data format:
• Baud rate 9600 (basic setting)
• Data bits 8
• Stop bits 1
• Parity none
The baud rate is adjustable (refer to the following
page); all other parameters are fixed.
Make certain that the settings of the printer corre-
spond to whose of the DM4 DL.
Refer to the printer operating manual for information
about setting the transfer parameters.
7-2 Issue 05, 01/01 Krautkramer DM4E / DM4 / DM4 DL
7.1 Printing data
In connection with a printer having a serial interface
(e.g. Epson FX), the DM4 DL offers you the possibility
to print adjustment and measurement data as well as
statistical data.
In the DM4 DLs SPEC menu certain adjustments can
be carried out for printing the data:
BAUD Setting the data transfer rate
LANG Language selection
REP Selection of printer driver
HEAD Print “File header” with general data
STAT Print statistical data
For printing your measurement report you need:
• A printer with serial interface RS 232
• A data cable TGDL/PC with adapter GCH1 for
connecting the DM4 DL to the printer Epson FX (or
GCH3 for a printer Seiko DPU 414).
Documenting measurement values (DM4 DL only) Printing data
Preparing the printer
– Using the cable TGDL/PC, connect the printer to
the DM4 DL via the serial interface RS 232.
Data transfer for the DM4 DL is made in the following
data format:
• Baud rate 9600 (basic setting)
• Data bits 8
• Stop bits 1
• Parity none
The baud rate is adjustable (refer to the following
page); all other parameters are fixed.
Make certain that the settings of the printer corre-
spond to whose of the DM4 DL.
Refer to the printer operating manual for information
about setting the transfer parameters.
