Krautkramer DM4E / DM4 / DM4 DL Issue 05, 01/01 5-13

Additional functions in the DM4 and DM4 DL Operation

5.4 Additional functions in the

DM4 and DM4 DL

The DM4 and the DM4 DL have further functions for

wall thickness measurement in the SPEC menu:

• Sensitivity setting (GAIN)

• Lower alarm limit setting (LO-L)

• Upper alarm limit setting (HI-L)

• Selection of Difference mode (DIF)

• Bandpass filter setting (FLTR)

• In addition to these, the DM4 DL also has functions

for data transfer (refer to Chapter 7).

Setting the sensitivity GAIN

You can change the sensitivity of the DM4 and the

DM4 DL. The selection of the sensitivity is dependent

on the characteristics of the material (structure, graini-

ness, paint layer etc.).

The basic setting Automatic changes the sensitivity

depending on the sound velocity.

Operation:

– Press m until SPEC appears.

– Press d or u until GAIN is displayed.

– Press c.

The active sensitivity set is displayed.

– Select the required sensitivity with d or u:

AUTO automatically sets the sensitivity on

LO low sensitivity

MED medium sensitivity

HI high sensitivity

– Acknowledge with c.
