Krautkramer DM4E / DM4 / DM4 DL Issue 05, 01/01 6-9
Viewing stored measurement values Operation of the Data Logger (DM4 DL only)
– With d or u you can select the memory location
at which the next measurement value is to be
stored.
– Press y twice.
The instrument again switches to the ready-for-mea-
surement state. The selected memory location is ac-
tive.
H Note:
The following chapter describes how you display indi-
vidual measurement values contained in the memory
locations.
6.4 Viewing stored measurement
values
You can have your measurement values in the Data
Logger displayed.
Operation:
– If necessary, select the file whose measurement
values you wish to see (refer to Page 6-5).
You are in the THK, THK/SPEC or MIN mode.
– Press y .
The active memory location number is displayed, e.g.
+L.001.
– Press u or d until the required memory location
appears.
– Press y again in order to display the stored
measurement value.
The measurement value is displayed in the selected
unit of measure.
Krautkramer DM4E / DM4 / DM4 DL Issue 05, 01/01 6-9
Viewing stored measurement values Operation of the Data Logger (DM4 DL only)
– With d or u you can select the memory location
at which the next measurement value is to be
stored.
– Press y twice.
The instrument again switches to the ready-for-mea-
surement state. The selected memory location is ac-
tive.
H Note:
The following chapter describes how you display indi-
vidual measurement values contained in the memory
locations.
6.4 Viewing stored measurement
values
You can have your measurement values in the Data
Logger displayed.
Operation:
– If necessary, select the file whose measurement
values you wish to see (refer to Page 6-5).
You are in the THK, THK/SPEC or MIN mode.
– Press y .
The active memory location number is displayed, e.g.
+L.001.
– Press u or d until the required memory location
appears.
– Press y again in order to display the stored
measurement value.
The measurement value is displayed in the selected
unit of measure.
