4 Description of the Pump (Set)
20 of 82
Amarex
2573.820/02-EN
Transportable wet-installed model (installation type P)
▪ Foot plate or pump stool with fasteners
▪ Lifting rope/ lifting chain
6)
NOTE
A separate name plate is included in the scope of supply.
This name plate must be attached in a clearly visible position outside the place of
installation, e.g. at the control panel, pipeline or mounting bracket.
4.9 Dimensions and weights
For dimensions and weights refer to the general arrangement drawing/outline
drawing or data sheet of the pump set.
6
Optional
