1 General
1.1 Principles
This operating manual is valid for the type series and variants indicated on the front
cover (for details, refer to the table below)
Table1: Variants covered by this operating manual
Size Impeller type Material variant
G G1 G2 GH
50-140 F F F F F
50-220 F F F F F
65-150 F F F F F
65-170 F F F F F
65-230 F F F F F
80-140 D D - D D
80-150 F F F F F
80-170 D D - D D
80-180 F, D F, D F F, D F, D
80-220 F F F F F
80-230 F, D F, D F F, D F, D
100-140 D D - D D
100-170 D D - D D
100-180 F, D F, D F F, D F, D
100-230 F, D F, D F F, D F, D
150-180 F F F F F
150-230 F, D F, D F F, D F, D
The operating manual describes the proper and safe use of this equipment in all
phases of operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
clearly identify the pump set and serve as identification for all further business
processes.
In the event of damage, immediately contact your nearest KSB service facility to
maintain the right to claim under warranty.
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB refer to the sub-sections under
Servicing/Maintenance.
1.3 Target group
This operating manual is aimed at the target group of trained and qualified specialist
technical personnel. (ðSection2.3,Page10)
1.4 Other applicable documents
Table2: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Hydraulic characteristic curve Characteristic curves showing head, flow rate,
efficiency and power input
