76 of 82
Amarex
2573.820/02-EN
9.5 Sectional drawings of the mechanical seal
Table36: Sectional drawings of the mechanical seal
Part No. Description Sectional drawing
Mechanical seal (bellows-type mechanical seal)
433.01 Mechanical seal (bellows-type mechanical seal)
433.01
433.02
932.03
UG1796735
932.03 Circlip
433.02 Mechanical seal (bellows-type mechanical seal)
Mechanical seal with covered springs
433.01 Mechanical seal (bellows-type mechanical seal)
433.01
433.02
932.03
UG1796735
29 mm
932.03 Circlip
433.02 Mechanical seal (mechanical seal with covered
springs, HJ)
