KSB Amarex User Manual

9 Related Documents
68 of 82
Amarex
2573.820/02-EN
9.2.5 List of components in the exploded views
Table32: List of components
Part No. Description Part No. Description
100 Casing 500 Ring
113 Intermediate casing 550 Disc
162 Suction cover 561 Grooved pin
182 Feet 69-6 Temperature sensor
210 Shaft 69-16 Moisture sensor
23-7 Impeller body 81-2 Plug
230 Impeller 81-59 Stator
321.01/.02 Radial ball bearing 818 Rotor
330 Bearing bracket 821 Rotor core pack
355 Bearing bracket housing 834 Cable gland
410 Profile seal 99-9 Set of sealing elements
411 Joint ring 903 Screw plug
412.01/.02/.03/.04/.05 O-ring 904 Grub screw
433.01/.02 Mechanical seal 914.01/.02/.03/.04/.06 Hexagon socket head cap screw
476 Mating ring carrier 932.01/.02/.03/.04 Circlip
59-17 Shackle

KSB Amarex Specifications

General

Material	Cast iron, stainless steel
Operating mode	Continuous
Type	Submersible Pump
Application	Sewage
Explosion protection	Available with explosion protection
Frequency	50 Hz, 60 Hz
Impeller Type	Multi-vane
