7 Servicing/Maintenance
48 of 96
Sewatec
Grease quality
The rolling element bearings are packed with lithium-soap grease at the factory.
For re-lubrication use grease of the following properties:
▪ Lithium soap
▪ Free of resin and acid
▪ Not liable to crumble
▪ The grease should have a penetration number between two and three,
corresponding to a worked penetration between 220 and 295mm/10.
▪ Its drop point must be above 175°C.
Grease quantity
For the first re-lubrication, a larger grease quantity is required as the cavities need to
be filled too.
Refer to the table below for the grease quantities.
Table17: Grease quantity
Bearing bracket size Re-lubrication
quantity
[g]
Additional grease quantity
for first re-lubrication
[g]
Radial bearing
(cylindrical roller
bearing 322.01)
Fixed bearing
(angular contact
ball bearing 320.02)
S05 25 75 200
S06 50 150 500
S07 / S08 70 350 700
S09 200 260 850
S10 Re-lubrication by automatic grease pump
Completely pack the bearings with grease; both side gaps should be
2
/
3
filled.
Re-lubrication interval
Table18: Re-lubrication interval
Bearing bracket size Re-lubrication intervals
in operating hours
[h]
S05 / S06 3000
S07 / S08 2000
S09 3000
S10 Re-lubrication by automatic grease pump
7.2.3.2 Checking the leakage chamber
WARNING
Fluids handled, consumables and supplies which are hot and/or pose a health
hazard
Hazard to persons and the environment!
▷ Collect and properly dispose of flushing fluid and any fluid residues.
▷ Wear safety clothing and a protective mask if required.
▷ Observe all legal regulations on the disposal of fluids posing a health hazard.
