7 Servicing/Maintenance
72 of 96
Sewatec
Check the gland packing during commissioning. Adjust the gland packing, if
required.
The gland packing must leak slightly during operation.
Prior to commissioning
1. Only lightly tighten the nuts of the gland follower by hand.
2. Use a feeler gauge to verify that the gland follower is mounted centred and at a
right angle to the shaft.
ð The gland must leak after the pump has been primed.
After five minutes of
operation
The leakage can be reduced.
1. Tighten the nuts of the gland follower by 1/6 turn.
2. Monitor the leakage for another five minutes.
Excessive leakage:
Repeat steps 1 and 2 until the minimum value has been reached.
Not enough leakage:
Slightly loosen the nuts at the gland follower.
No leakage:
Switch off the pump set immediately!
Loosen the gland follower and repeat start-up.
Checking for leakage
After the leakage has been adjusted, monitor the leakage for about two hours at
maximum fluid temperature.
Check that enough leakage occurs at the gland at minimum inlet pressure.
7.5.9 Mounting the motor
Version with coupling
NOTE
Steps 1 and 2 do not apply to versions with spacer-type coupling.
1. Shift the motor to connect it to the pump via the coupling.
2. Fasten the motor to the baseplate.
3. Align the pump and motor. (ðSection5.9,Page32)
4. Connect the motor to the power supply (refer to manufacturer's product
literature).
Version with belt drive
WARNING
Motor tipping over
Risk of squashing hands and feet!
▷ Suspend or support the motor to prevent it from tipping over.
1. Fasten the motor to motor plate 81-33 with bolts 901.65, discs 550.65 and nuts
920.65.
2. Screw motor plate 81-33 including motor to motor bracket 890.
3. Screw in height-adjusting elements 901.59 / 550.59.
4. Mount motor bracket 890 on baseplate.
