5 Installation at Site
5.1 General information/Safety regulations
DANGER
Using damaged cables in a well
Electric shock!
▷
Do not kink cables (observe the minimum bending radius
6)
of the cable) or
drag the cables over sharp edges.
▷ Use cable ties or other suitable fasteners to fasten the power cables as well as
any measuring and control cables to the riser or piping every three meters.
▷ Do not use any tools, equipment or accessories with sharp edges (e.g. sharp-
edged pipe sockets) during installation.
WARNING
Pump set falling into the well
Personal injury or persons being dragged down by uncontrolled cable movements!
Damage to the pump set and the well!
▷ Securely store the cable with extension lead. Keep at a safe distance during
installation.
▷ Secure the pump set during the entire installation procedure.
▷ Dimension any securing devices (supporting clamps, supports, etc.) so that they
can carry all weights during the installation.
WARNING
Persons could fall into unsecured wells/reservoirs/tanks
Risk of personal injury!
▷ During installation work, take suitable precautions to protect anyone from
falling into an open well/reservoir/tank.
▷ Suitably fence off the work area.
WARNING
Improper handling when setting the pump set down in a vertical/horizontal
position
Personal injury and damage to property!
▷ Use appropriate means to secure the pump set against overturning, tipping
over and rolling off.
▷ Maintain adequate safety distance during lifting operations (load may swing
when being lifted).
▷ Use additional supports for the transport holder to secure the pump set against
overturning.
WARNING
Improper handling of the power cable when placing the pump set in vertical
position or transporting it
Personal injury and damage to property!
▷ Secure power cables against falling down.
6)
See cable manufacturer's documentation or DIN VDE 0298-3.
5 Installation at Site
20 of 64
UPA, UPZ, BSX
