1 General
1.1 Principles
This manual is supplied as an integral part of the type series and variants indicated
on the front cover (see details listed below).
▪ UPA 250C
▪ UPA 300
▪ UPA 350
▪ UPZ
▪ BSX
▪ BRY
▪ BRZS
▪ BRE
▪ BSF
▪ T
▪ V
▪ X
▪ Z
▪ E
The manual describes the proper and safe use of this equipment in all phases of
operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
uniquely identify the pump (set) and serve as identification for all further business
processes.
In the event of damage, immediately contact your nearest KSB service centre to
maintain the right to claim under warranty.
1.2 Target group
This manual is aimed at the target group of trained and qualified specialist technical
personnel.(⇨ Section 2.4 Page 9)
1.3 Other applicable documents
Table 1: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Hydraulic characteristic curve Characteristic curves showing head, NPSH
required, efficiency and power input
General assembly drawing
1)
Sectional drawing of the pump
Sectional drawing of the motor
Sub-supplier product literature
1)
Operating manuals and other product literature
describing accessories and integrated machinery
components
Spare parts lists
1)
Description of spare parts
Operating manual for
accessories
1)
Description of accessories, e.g. cable connector
Pump sizes
Motor sizes
1)
If agreed to be included in the scope of supply
1 General
6 of 64
