Table 22: List of components
Part No. Description Part No. Description
106 Suction casing 75-6 Plate guide
108 Stage casing 751 Valve housing
143 Suction strainer 752.11/.12 Valve seat
211 Pump shaft 753 Valve disc
232 Clockwise impeller 756 Valve spring
270 Deflector 759 Valve plate
412.01 O-ring 81-39 Clamp
58-1 Protecting plug 825 Cable guard
502.01/.02 Casing wear ring 849 Sleeve coupling
503 Impeller wear ring 900.01 Screw
520 Sleeve 901.01/.02/.11 Hexagon head bolt
525.01 Spacer sleeve 902.01/.02/.11 Stud
529.01/.02 Bearing sleeve 904.03 Grub screw
540 Bush 914.11 Hexagon socket head cap screw
545.01/.02 Bearing bush 920.01/.11 Nut
550.01/.11 Disc 931 Lockwasher
940.01/.02/.03/.
04/.05
Key
9 Related Documents
UPA, UPZ, BSX
55 of 64
