15 ELECTRICAL SYSTEM 145
15.11 Changing the turn signal bulb (Duke)
Note
Damage to reflector Reduced brightness.
– Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before
mounting.
V00066-10
– Remove the screw on the rear of the turn signal housing.
–
Remove turn signal glass
.
– Press the bulb carefully into the socket, turn it counterclockwise by about 30°, and pull
it out of the socket.
Info
Do not touch the reflector with your fingers and keep it free from grease.
– Lightly push the new lamp into the socket and turn all the way clockwise.
Turn signal (RY10W / socket BAU15s) ( p. 182)
– Position the turn signal glass.
– Insert the screw and first turn counterclockwise until it engages in the thread with a
small jerk. Tighten the screw lightly.
– Check that the turn signal system is functioning properly.
