7 COMBINATION INSTRUMENT 50
Press the UP or DOWN button until the current day is set.
Press the SET button.
The month next to "Date" flashes.
Press the UP or DOWN button until the current month is set.
Press the SET button.
The year next to "Date" flashes.
Press the UP or DOWN button until the current year is set.
Press the BACK button.
Time and date are saved.
7.24 "Shift Light"
K00394-01
Condition
The vehicle is stationary.
Press the UP or DOWN button until the "Settings" menu appears on the display. Pressing
the SET button opens the menu.
Press the UP or DOWN button until the "Shift Light" menu is marked on the display.
Pressing the SET button again opens the menu.
Press the UP or DOWN button to select the function. Use the SET button to set the
engine speed for the gear shift recommendation.
When the engine speed reaches "RPM 1", the speed display lights up red.
When the engine speed reaches "RPM 2", the speed display flashes red.
Switch the "Shift Light" function on or off.
