6 CONTROLS 29
6.5.2 Electric starter button
K00349-12
The electric starter button
is fitted on the right side of the handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button pressed – In this position, the electric starter is actuated.
6.5.3 Ignition/steering lock
B00925-01
The ignition/steering lock is in front of the upper triple clamp.
Possible states
Ignition off – In this position, the ignition circuit is interrupted, a running
engine stops, and a non-running engine will not start. The ignition key can
be removed.
Ignition on – In this position, the ignition circuit is closed and the engine
can be started.
Steering locked – In this position, the ignition circuit is interrupted and the
steering locked. The ignition key can be removed.
