21 TROUBLESHOOTING 172
Faults Possible cause Action
Engine overheats Too little coolant in cooling system Check the cooling system for leakage.
Check the coolant level in the compensating
tank. ( p. 150)
Radiator fins very dirty Clean radiator fins.
Foam formation in cooling system Drain the coolant. ( p. 152)
Fill/bleed the cooling system. ( p. 153)
Buckled or damaged radiator hose Change the radiator hose.
Thermostat is faulty Check the thermostat.
Fuse 4 blown Change the fuses of individual power consumers.
( p. 135)
Defect in radiator fan system Check the radiator fan system.
FI warning lamp (MIL) lights/flashes Defect in fuel injection system Read out the fault memory using the KTM diag-
nostics tool.
N The idle indicator lamp does not
light up when the transmission is in
neutral
Gear position sensor not programmed Read out the fault memory using the KTM diag-
nostics tool.
Engine dies during the trip Lack of fuel Refuel. ( p. 67)
Fuse 1, 2 or 3 blown Change the fuses of individual power consumers.
( p. 135)
The ABS warning lamp lights up ABS fuse is blown Change the ABS fuses. ( p. 134)
Large difference in wheel speeds of the
front and rear wheels
Stop the vehicle, switch off the ignition, and
start it again.
Malfunction in ABS Read out the ABS fault memory using the KTM
diagnostics tool.
High oil consumption Engine vent hose bent Route the vent hose without bends or change it if
necessary.
