22 TECHNICAL DATA 189
Screw, top shock absorber M10x1.25 50 Nm (36.9 lbf ft) Loctite
®
243™
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –
Nut, frame to linkage lever M14x1.5 100 Nm (73.8 lbf ft) –
Nut, linkage lever on swingarm M14x1.5 100 Nm (73.8 lbf ft) –
Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft) –
Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –
Screw, steering head M20x1.5 40 Nm (29.5 lbf ft) –
Adjusting ring of swingarm bearing M24x1.5 25 Nm (18.4 lbf ft) –
Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) –
Nut, steering head M28x1 12 Nm (8.9 lbf ft) –
