Trunk system
The Motorcycle is equipped with two side trunks and one top case. All of
the trunks can be locked. The keys will lock/unlock both the rack and the
trunk lids. All racks and lids must be locked while driving.
To open the trunk, unlock the trunk lid locks
4, fold up the clip and detach
the hook from the trunk lid.
To remove the trunks, unlock the retaining locks, fold up the clip
1,
detach the hook
2 and tilt the back to the side.
To mount, attach the front of the trunks to the frame, insert the rear in the
lock plate
3, attach the hook 2 and fold down the clip 1.
After unlocking the retaining locks and unlatching, pull the top case back
from the frame. When mounting, make sure the front and bottom of the
top case latch in position on the frame.
Maximum trunk load:
Left trunk.............10 kg
Right trunk ..........10 kg
Top case ..............5 kg
Make sure to distribute your luggage evenly among the trunks.
WARNING
N
EVER DRIVE FASTER THAN 130 KPH WITH A TOP CASE AND TRUNKS.
!
CAUTION
!
–LOCK ALL RETAINING LOCKS AND LID LOCKS BEFORE DRIVING OFF.
–D
O NOT OVERLOAD THE TRUNKS.
Center stand / side stand
Either park the vehicle on the center stand 6 or the side stand 7.
Grab handle
The passenger can old on to the two grab handles 5.
10
