Collar nut for front wheel spindle M16x1,5 40 Nm
Collar nut for rear wheel spindle M20x1,5 80 Nm
Shock absorber, top M10 45 Nm
Shock absorber, bottom M10 45 Nm
Collar screw, rear brake disk M6 Loctite 243 + 10Nm
Collar screw, front brake disk M6 Loctite 243 + 10Nm
Screws on front brake caliper M8 Loctite 243 + 25 Nm
Collar nuts for bearing bolt linkage arm/frame M12 60 Nm
Collar nuts for rocker arm bolt M14x1,5 100 Nm
Engine cradle bolt M10 45 Nm
Ball joint for push rod M8 Loctite 243 + 25 Nm
Rear sprocket screws on nut M8 Loctite 243 + 35 Nm
Collar nut for swing arm bolt M14x1,5 100 Nm
Clamp screws for upper triple clamp M8 20 Nm
Clamp screws for lower triple clamp M8 15 Nm
Clamp screws for fork legs M8 10 Nm
Collar screws for handlebar clamp M8 Loctite 243 + 20 Nm
HH screw for handlebar mount, dampened M10 Loctite 243 + 20 Nm
Rim lock M8 5 Nm
Steering stem clamping M8 20 Nm
Subframe M8 Loctite 243 + 35 Nm
Spoke nipple 4 Nm
Screw to adjust the spring preload on the shock absorber M6 8 Nm
Other chassis screws M6 10 Nm
M8 25 Nm
M10 45 Nm
Other collar nuts on chassis M6 15 Nm
M8 30 Nm
M10 50 Nm
TIGHTENING TORQUES - CHASSIS
COMPARISON OF AUTOMOTIVE FLUIDS
Recommended by KTM NATO number
Fuel: unleaded premium-grade fuel with at least 91 octane ROZ F-67
Engine Oil: ( > 0°C ) Motorex Power Synt 4T 10W50 0-236
( < 0°C ) Motorex Power Synt 4T 5W40 0-1178
Chain spray: Motorex Chainlube 622 -
Coolant: Motorex Anti- Freeze -
Air filter cleaner: Motorex Bio Dirt Remover -
Air filter oil: Motorex Liquid Bio Power -
Grease: Motorex Long Therm 2000 NLGI1 or NLGI2
Brake fluid: Motorex Brake Fluid DOT 5.1 H-542
Oil for hydraulic clutch: Motorex clutch fluid 75 -
Fork oil: Motorex SAE 5 -
Shock absorber oil : Motorex shock absorber oil -
46
