MAINTENANCE WORK ON CHASSIS AND ENGINE 127
600613-01
– Use a screwdriver (see illustration) to adjust the headlight range.
Guideline
The boundary between light and dark must be exactly on the lower mark for a motor-
cycle with a rider (mark is applied under: Checking headlight adjustment).
Info
Turn clockwise to increase the light range, turn counterclockwise to reduce the
light range.
If you have a payload, you may have to correct the headlight range.
9.67Removing the air filterx
– Remove the seat. ( S. 110)
100285-10
– Remove screws. Remove filter box top.
