LOCATION OF SERIAL NUMBERS 22

4LOCATION OF SERIAL NUMBERS

4.1

Chassis number

100217-10

The chassis number is stamped on the steering head on the right.

4.2Type label

100218-10

Type label is located on the upper right frame tube below the seat.
