OPERATING ELEMENTS 30
5.11Electric starter button
100226-10
The electric starter button is fitted on the right side of the handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button pressed –In this position, the electric starter is actuated.
5.12Ignition/steering lock
100236-10
The ignition/steering lock is located in front of the seat.
Possible states
Ignition off –In this position, the ignition circuit is interrupted, a running
engine stops, and a non-running engine will not start. The ignition key can
be removed.
Ignition on –In this position, the ignition circuit is closed, and the engine
can be started.
Steering locked –In this position, the ignition circuit is interrupted and the
steering locked. The ignition key can be removed.
