KTM 690 SMC User Manual

TECHNICAL DATA - ENGINE 160
6th gear 23:20
Mixture preparation Electronic fuel injection
Ignition Contactless controlled fully electronic ignition with digital ignition
adjustment
Generator 12V, 224W
Spark plug NGK LKAR 8AI - 9
spark plug electrode gap 0.9mm (0.035in)
Cooling Water cooling, permanent circulation of coolant by water pump
Starting aid Electric starter, automatic decompressor
15.1Capacity - engine oil
Engine oil 1.70l (1.8qt.) Engine oil (SAE 10W/60) ( S. 174)
15.2Capacity - coolant
Coolant 1.20l (1.27qt.) Coolant ( S. 173)
Coolant (mixed ready to use) ( S. 173)

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
