OPERATING ELEMENTS 38
5.25Combination instrument -TRIPF display
700123-01
When the fuel level reaches the reserve mark, the display automatically changes toTRIPF
and begins to count from0.0, regardless of which display mode was previously active.
Info
Parallel to theTRIPF display, the fuel warning light begins to light up.
5.26Combination instrument - coolant temperature indicator
700124-01
The temperature indicator in the display consists of 12 bars. The more bars that light up,
the hotter the coolant. When the top bar lights up, all bars begin to flash simultaneously
and the temperature warning lamp begins to light up.
Possible states
• Engine cold –up to four bars light up.
• Engine at normal operating temperature –from five to eleven bars light up.
• Engine hot –all twelve bars flash.
