23 TECHNICAL DATA 191

Screw, air filter box, on frame M6 6 Nm (4.4 lbf ft) –

Screw, battery compartment M6 6 Nm (4.4 lbf ft) –

Screw, brake fluid container, front brake M6 8 Nm (5.9 lbf ft) –

Screw, brake fluid container, rear brake M6 7 Nm (5.2 lbf ft) –

Screw, brake line guide on bottom triple

clamp

M6 7 Nm (5.2 lbf ft) Loctite

243™

Screw, cable holder, side stand switch M6 9 Nm (6.6 lbf ft) Loctite

243™

Screw, chain guard M6 7 Nm (5.2 lbf ft) –

Screw, chain sliding guard M6 7 Nm (5.2 lbf ft) –

Screw, compensating tank M6 9 Nm (6.6 lbf ft) –

Screw, engine sprocket cover on frame M6 7 Nm (5.2 lbf ft) –

Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft) Loctite

243™

Screw, footrest bracket M6 7 Nm (5.2 lbf ft) –

Screw, front fender on axle clamp M6 7 Nm (5.2 lbf ft) –

Screw, front fender, top side M6 7 Nm (5.2 lbf ft) –

Screw, front mask M6 7 Nm (5.2 lbf ft) –

Screw, front mask structure on headlight

bracket

M6 6 Nm (4.4 lbf ft) –

Screw, front seat fixing M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler M6 7 Nm (5.2 lbf ft) –

Screw, front spoiler retaining bracket,

rear

M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler retaining bracket,

rear, on engine

M6 9 Nm (6.6 lbf ft) –

Screw, front spoiler, right, on footrest

bracket

M6 7 Nm (5.2 lbf ft) –
