23 TECHNICAL DATA 192

Screw, ground cable, on frame M6 7 Nm (5.2 lbf ft) –

Screw, handlebar stub M6 7 Nm (5.2 lbf ft) Loctite

243™

Screw, ignition coil M6 9 Nm (6.6 lbf ft) –

Screw, ignition lock M6 11 Nm (8.1 lbf ft) –

Screw, license plate holder on license

plate bracket

M6 7 Nm (5.2 lbf ft) –

Screw, magnetic holder on side stand M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, mirror holder M6 9 Nm (6.6 lbf ft) –

Screw, passenger seat M6 7 Nm (5.2 lbf ft) –

Screw, radiator air inlet, on frame M6 6 Nm (4.4 lbf ft) –

Screw, radiator holder M6 6 Nm (4.4 lbf ft) –

Screw, rear ABS sensor wheel (RC 125) M6 6 Nm (4.4 lbf ft) Loctite

204™

Screw, rear fender M6 7 Nm (5.2 lbf ft) –

Screw, retaining bracket, EFI control

unit

M6 6 Nm (4.4 lbf ft) –

Screw, shift lever linkage M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, side cover M6 7 Nm (5.2 lbf ft) –

Screw, side cover on front mask M6 6 Nm (4.4 lbf ft) –

Screw, voltage regulator M6 11 Nm (8.1 lbf ft) –

Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft) –

Screw, wheel speed sensor holder

(RC 125)

M6 8 Nm (5.9 lbf ft) –

Screw, windshield M6 9 Nm (6.6 lbf ft) –

Fitting, engine mounting bracket M8 48 Nm (35.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Questions and Answers:

Need help?

Do you have a question about the KTM RC 200 and is the answer not in the manual?

KTM RC 200 Specifications

General

Displacement	199.5 cc
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP APEX Monoshock
Bore x Stroke	72 mm x 49 mm
Compression Ratio	11.5:1
Max Power	25 PS @ 10000 rpm
Max Torque	19.2 Nm @ 8000 rpm
Front Brake	300 mm disc
Rear Brake	230 mm disc
Fuel Tank Capacity	13.7 liters
Kerb Weight	160 kg
Front Suspension	WP APEX 43 mm Upside Down
ABS	Dual Channel
Tyre Front	110/70-17
Tyre Rear	150/60-R17
Ground Clearance	157 mm
Engine Type	Single Cylinder, Liquid Cooled
