21 TECHNICAL SPECIFICATIONS
100
21.2 Chassis
Frame Central tube frame of chrome molybdenum steel tub-
ing, powder-coated
Fork (SX‑E 3) WP XACT
Fork (SX‑E 5) WP XACT
Shock absorber (SX‑E 3) WP Suspension
Shock absorber (SX‑E 5) WP XACT 5735
Standard rider weight (SX‑E 3) 15 … 35 kg (33 … 77 lb.)
Standard rider weight (SX‑E 5) 25 … 35 kg (55 … 77 lb.)
Suspension travel (SX‑E 3)
front 144 mm (5.67 in)
rear 133 mm (5.24 in)
Suspension travel (SX‑E 5)
front 205 mm (8.07 in)
rear 185 mm (7.28 in)
Fork offset 22 mm (0.87 in)
Brake system
front Disc brake with 2-piston brake caliper
rear Disc brake with 2-piston brake caliper
Brake disc diameters
front 160 mm (6.3 in)
rear 160 mm (6.3 in)
Brake discs - wear limits
front 2.2 mm (0.087 in)
rear 2.2 mm (0.087 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary drive ratio 08:46
Chain 1/2 x 3/16”
Rear sprockets available 45, 46, 47
Steering head angle (SX‑E 3) 63°
Steering head angle (SX‑E 5) 66°
Wheelbase (SX‑E 3) 1,017 mm (40.04 in)
Wheelbase (SX‑E 5) 1,032 mm (40.63 in)
Seat height unloaded (SX‑E 3) 555 … 600 mm (21.85 … 23.62 in)
Seat height unloaded (SX‑E 5) 615 … 665 mm (24.21 … 26.18 in)
Ground clearance unloaded (SX‑E 3) 152 mm (5.98 in)
Ground clearance unloaded (SX‑E 5) 252 mm (9.92 in)
Ready-to-ride weight approx. (SX‑E 3) 39.2 kg (86.4 lb.)
Ready-to-ride weight approx. (SX‑E 5) 40.5 kg (89.3 lb.)
Maximum permissible overall weight (SX‑E 3) 80 kg (176 lb.)
Maximum permissible overall weight (SX‑E 5) 95.5 kg (210.5 lb.)
