13 SERVICE WORK ON THE CHASSIS
56
M01683-10
–
Mount and tighten screw
2
.
Guideline
Screw, start number
plate
M6 4 Nm (3 lbf ft)
13.16 Removing front fender
H01428-10
–
Remove screws
1
. Take off the front fender.
13.17 Installing front fender
M01671-10
–
Position the fender with drill holes
1
in the holding lugs on
the start number plate.
H01428-11
–
Position front fender. Mount and tighten screws
2
.
Guideline
Screw, fender M6 6 Nm (4.4 lbf ft)
