SERVICE WORK ON THE CHASSIS 13
59
13.22 Mounting the seat
M01684-10
–
Hook the seat onto holding lug
1
, lower the seat at the rear,
and push it forward.
Holding lug
2
hangs on the front fairing.
H00066-11
–
Close quick release
3
.
13.23 Checking the chain for dirt
400678-01
– Check the chain for coarse dirt accumulation.
» If the chain is very dirty:
– Clean the chain. ( p. 59)
13.24 Cleaning the chain
Warning
Danger of accidents Lubricants on the tires reduces the road grip.
– Remove lubricants from the tires using a suitable cleaning agent.
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, cleaning agents, brake fluid etc. properly and in compliance with the applica-
ble regulations.
