TECHNICAL SPECIFICATIONS 21
103
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 3 mm (0.12 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 25 N/mm (143 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
30 N/mm (171 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 35 N/mm (200 lb/in)
Spring length 130 mm (5.12 in)
Gas pressure 10 bar (145 psi)
Static sag 12 mm (0.47 in)
Riding sag 80 mm (3.15 in)
Fitted length 275 mm (10.83 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 105)
21.7 Chassis tightening torques
Screw, brake line holder on fork
protector
EJOT PT
®
K60x20‑AL 2 Nm (1.5 lbf ft)
Screw, brake line holder on link
fork
EJOT SF
®
M5x10‑K 2 Nm (1.5 lbf ft)
Screw, seat quick release thrust
bearing
- 0.65 Nm (0.479 lbf ft)
Screw, magnetic switch on handle-
bar
M3 0.8 Nm (0.59 lbf ft)
Spoke nipple M3.5 3 Nm (2.2 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, throttle grip M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, brake assembly M5 5 Nm (3.7 lbf ft)
Screw, brake linings M5 8 Nm (5.9 lbf ft)
Nut, push rod ball joint on the rear
brake cylinder (SX‑E 5)
M6 10 Nm (7.4 lbf ft)
Nut, push rod, foot brake lever
(SX‑E 5)
M6 6 Nm (4.4 lbf ft)
Rear fairing screw M6 8 Nm (5.9 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, chain sliding guard M6 3 Nm (2.2 lbf ft)
Screw, fender M6 6 Nm (4.4 lbf ft)
Screw, fork stub M6 10 Nm (7.4 lbf ft)
