21 TECHNICAL SPECIFICATIONS
104
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, splash protector M6 7 Nm (5.2 lbf ft)
Screw, start number plate M6 4 Nm (3 lbf ft)
Screw, subframe connection M6 10 Nm (7.4 lbf ft)
Threaded adapter for front fairing M6 8 Nm (5.9 lbf ft)
Nut, foot brake lever (SX‑E 5) M8 22 Nm (16.2 lbf ft)
Nut, rim lock M8 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, chain securing guide M8 15 Nm (11.1 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, front brake caliper M8x35 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, LV traction battery, front M8x25 20 Nm (14.8 lbf ft)
Screw, LV traction battery, rear M8x50 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, rear brake caliper M8x20 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, rear sprocket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft)
Screw, subframe M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 20 Nm (14.8 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10x52 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, front wheel spindle M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10x42 45 Nm (33.2 lbf ft)
Loctite
®
243™
Nut, rear wheel spindle M12x1 40 Nm (29.5 lbf ft)
Nut, swingarm pivot M12x1 45 Nm (33.2 lbf ft)
Nut, steering head M20x1.5 10 Nm (7.4 lbf ft)
