Page #124 background image
System Specifications
54-0161
127
Appendix A
System Specifications
A.1 Antenna Specifications
Physical Characteristics
Antenna Unit 27.4" (70 cm) h x 26.2" (67 cm) d;
55 lbs (25 kg)
External Sensor 7.8" (19.8 cm) l x 5" (12.7 cm) w x
5" (12.9 cm) h
ADCU 7.3" (18.5 cm) d x 8.2" (20.8 cm) w x
2.6" (6.6 cm) h
Operating temperature -13°F to +130°F (-25°C to +55°C)
Storage temperature -40°F to +185°F (-40°C to +85°C)
Input Power
Input 11–16 VDC @ 3.5 amps nominal
(4.5 amps peak)
Antenna System Performance
Minimum EIRP 47 dBW
Elevation range 10°- 80°
Azimuth range 720°
Pitch/roll range ±15°
Pitch/roll rate 30°/second
Turn rate 45°/second
Yaw ±90° in 10 seconds
Tracking rate 30° per second
Position repeatability 0.1°
Surge/sway/heave ±0.2 G
Shock 20 G, 11 msec
Vibration 0.9 G rms over 5-33 Hz
Table A-1
TracVision G6 Antenna
Physical Specifications
Table A-2
TracVision G6 Power Specifications
Table A-3
TracVision G6 Performance
Specifications
